1) Frame work Design & material
The machine adopts vertical plate frame structure, frame work is made of Q235B first-grade whole plate material, numerical control cutting, welded under CO2 gas protection, through thermal aging treatment and machining, guarantee the metallicity and strength of extension of the frame.
The parallelism guarantee the pattern and uniform glossiness of embossing leather.
2)Degree of Uniformity
Due to the frame after thermal aging treatment ，guarantee no deformation of long use life. By mechanical processing, upper and lower surface precision within +-0.05,which enable the degree of uniformity.
3)Repetition raising Pressure
The machine has function of repetition of raising pressure, which enhances embossing effect . customer can make the number of repetition raising pressure according to leather technique, can reach to 9,999 at most,
4)Pressure keeping capability
The hydraulic pressure system adopts two intake plug installing system, the valve is airtight. Both of the big and small cylinders keep the pressure .
The GB standard states that keeping 20Mpa status allows decompression 20kg in 10 seconds, but we can reach that decompression 20kg in 99 seconds
5)Energy efficient & heat rising Rate
The heating power is 22.5kW, under constant temperature control. About 35 minutes indoor temperature can reach to 100℃ ,then will be constant temperature,power consumption is relatively small to save energy.
6)Operating life Period
Operating life is directly related to frequency of use and maintenance. Can use for 15 years (8 hours working perday) within the scope of design pressure.
7)Safety Condition
We use electric control system to enable safety. Use approach switch, series circuit of four switch lock .The user can not operate if any one is not connected. Emergency stop switch and flap also guarantee the safety.
8)Special Performance
Manual and auto modes can make changing the plate easily.
Radiator fan can control the temperature of hydraulic oil.
Ultrahigh pressure alarm and security protection.
Filter entrance and return of hydraulic oil.
Filter clogging alarm.
